Non Pollution Electric Thermal Oil Boiler Automatic Running Large Output

    Buy cheap Non Pollution Electric Thermal Oil Boiler Automatic Running Large Output from wholesalers

    Buy cheap Non Pollution Electric Thermal Oil Boiler Automatic Running Large Output from wholesalers
    • Buy cheap Non Pollution Electric Thermal Oil Boiler Automatic Running Large Output from wholesalers

    Non Pollution Electric Thermal Oil Boiler Automatic Running Large Output

    Ask Lasest Price
    Brand Name : Yinyu
    Model Number : DRYL
    Certification : ISO/BV
    Price : $5,000.00-$10,000.00
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100 Qty/per month
    Delivery Time : 7-30 work days
    • Product Details
    • Company Profile

    Non Pollution Electric Thermal Oil Boiler Automatic Running Large Output

    Non Pollution High Efficiency Automatic Electric Heating Thermal Oil Boiler


    The increase in electrical energy is due to the increase in power in the conversion of heat energy, because the electric heating pipe is in contact with the thermal oil lead to the local temperature is too high, and the thermal oil encountered high temperature after the production of fission, coking, carbon build-up is the product of high temperature fission, day after day accumulated to the surface of the electric heating tube, these coking, carbon accumulation is very good formation of high-strength thermal resistance, heat can not be transferred to the heating oil in a timely manner, if the heat ingrestic damage will not occur in time. Then when used in its equipment to regularly clean the equipment and electric heating pipe, and cleaning materials are generally thermal oil on-line cleaning agent, directly into the system running cycle, will actively and carbon accumulation from the electric heating pipe and equipment peeled off to gradually decompose into fine particles, restore the temperature required in the past. Heat-conducting oil in use also regularly test its indicators are normal, if beyond the national value to immediately stop use, cleaning equipment after replacing new oil.

    Non Pollution Electric Thermal Oil Boiler Automatic Running Large Output


    Part of product parameters


    YY(Q)W-700Y(Q)


    NO;NameUnitNumberDescription
    1Rated thermal powerKW700
    2Rated working powerMpa1.0
    3Rated inlet/outlet ℃310/290
    4Design efficiency

    92.45(Oil)

    92.13(Gas)

    5Boiler heat efficiencyMore than 98%Be added economizer
    6Design fuels/Light oil,Gas
    7Fuels LHVMJ/kg42.917(Oil)
    MJ/Nm335.438(Gas)
    8Consumption of fuelskg/h70.77(Oil)
    Nm³/h86.53(Gas)Be added economizer
    9Radiation heating area7.199
    Convection heating area28.71
    GGH heating area10.965
    10Fume temperature136.68(Oil)
    137.02 (Gas)
    11Fume temperature60-80Be added economizer
    12Excess air coefficient/1.15
    13Volumem30.46
    14Bulk weightkg4250
    15Bulk sizemm3256×1727×2181
    16ChimneymmΦ325×10000
    17Combustion model/Micro positive pressureChamber combustion
    18Boiler structure featureHorizontal-type chamber combustion
    19Control wayFull automation/Manual
    20Ignition wayHigh-tension/Electrode

    YY(Q)W-1400Y(Q)


    NO;NameUnitNumberDescription
    1Rated thermal powerKW1400
    2Rated working powerMpa1.0
    3Rated inlet/outlet ℃310/290
    4Design efficiency

    92.33(Oil)

    92.03(Gas)

    5Boiler heat efficiencyMore than 98%Be added economizer
    6Design fuels/Light oil,Gas
    7Fuels LHVMJ/kg42.917(Oil)
    MJ/Nm335.438(Gas)
    8Consumption of fuelskg/h138.93(Oil)
    Nm³/h169.53(Gas)Be added economizer
    9Radiation heating area13.124
    Convection heating area71.233
    GGH heating area29.845
    10Fume temperature139.26(Oil)
    139.27 (Gas)
    11Fume temperature60-80Be added economizer
    12Excess air coefficient/1.15
    13Volumem31.08
    14Bulk weightkg8389
    15Bulk sizemm4869×2070×2698
    16ChimneymmΦ400×10000
    17Combustion model/Micro positive pressureChamber combustion
    18Boiler structure featureHorizontal-type chamber combustion
    19Control wayFull automation/Manual
    20Ignition wayHigh-tension/Electrode
    Our services

    Pre-sale service:
    We help customer choose the best boiler model according to

    different requirements of various industry. Before delivery we

    will provide foundation drawing, layout drawing, boiler room

    layout, etc.
    In-sale service:
    We keep 24 hours online and keep close contacts during the

    production process to ensure on time delivery with perfect

    finished product.
    After-sale service:

    1. provide full range of original spare parts.
    2. Engineers abroad installation and commissioning service is

    available.
    3. Our engineers will held a training for boiler workers to

    ensure the safe operation.
    4. Free maintenance and repair for one year and lifelong

    service.

    Boiler application areas
