Widely Used Low Pressure Operation easily Gas Fired Oil Fired Steam
Boiler
Boilers are widely used, industrial and civil, the following
enterprises will use steam boilers: steam boilers through heat
exchangers, the heat of steam exchange to water, water heating, and
then heating, heating, bathing, production and other uses.
Food industry: food processing, medical industry and filling
bottles and cans, etc. used as disinfection, food industry can be
used as steamed meat, rice. Wine also uses steam.
In the petrochemical industry, steam can heat oil and increase
liquidity.
Steam is also used in the petrochemical production process.
Production enterprises, the use of steam is more extensive, such as
insulation foam board, production with steam heating raw material
foaming production. The wood used to make furniture should be dried
by steam in order to make furniture. The aeganding bricks for
construction also need to be dried with steam, and power generation
can also be generated.
Washing ironing industry: dry cleaner, dryer, washing machine,
dewatering machine, ironing machine, ironing and other equipment
supporting the use of
Packaging machinery industry: labeling machine, set of standard
machine supporting the use of
Biochemical industry: fermentation tanks, reactors, laminated pots,
mixers, emulsifiers and other equipment supporting the use of
Food machinery industry: tofu machine, steaming box, sterilizing
tank, packaging machine, paint equipment, sealing machine and other
equipment supporting the use of
Other industries: (oil fields, automobiles) steam cleaning
industry, (hotels, dormitories, schools) steam or hot water supply,
(bridges, railways) concrete maintenance.
Etc
Product parameter:
WNS2-1.25-YQ
| NO; | Name | Unit | Number | Description |
| 1 | Rated evaporation | t/h | 2 | |
| 2 | Rated working power | Mpa | 1.25 | |
| 3 | Rated outlet ℃ | ℃ | 193 | |
| 4 | Design efficiency | ％ | 92.6(Oil)
92.46(Gas) | |
| 5 | Boiler heat efficiency | ％ | More than 98% | Be added economizer |
| 6 | Design fuels | / | Light oil,Gas | |
| 7 | Fuels LHV | MJ/kg | 42.917(Oil) | |
| MJ/Nm3 | 35.438(Gas) | |
| 8 | Consumption of fuels | kg/h | 137.9(Oil) | |
| Nm³/h | 167.325(Gas) | Be added economizer |
| 9 | Radiation heating area | m² | 8.527 | |
| Convection heating area | m² | 41.838 | |
| GGH heating area | m² | 23.195 | |
| 10 | Fume temperature | ℃ | 137.863(Oil) | |
| ℃ | 134.28 (Gas) | |
| 11 | Fume temperature | ℃ | 60-80 | Be added economizer |
| 12 | Excess air coefficient | / | 1.15 | |
| 13 | Volume | m3 | 5 | |
| 14 | Bulk weight | kg | 9700 | |
| 15 | Bulk size | mm | 4531×2150×2544 | |
| 16 | Chimney | mm | Φ500×10000 | |
| 17 | Total power consumption | KW | Oil:13,Gas:11 | |
| 18 | Combustion model | / | Micro positive pressure | Chamber combustion |
| 19 | Boiler structure feature(Three-pass structure) | Horizontal-type chamber combustion |
| 20 | Control way | Full automation/Manual |
| 21 | Ignition way | High-tension/Electrode |
