5,600 KW Non Pollution And Fully Automatic Electric Heating Hot
Water Boiler
How to choose a hot water boiler
First, determine the use of boilers, such as heating or bathing or
drinking boiled water;
Second, to provide conditions of use to determine the heat used by
the boiler, such as heating area or the amount of hot water used or
the number of people to drink boiled water;
Third, determine the boiler fuel, coal or fuel or gas;
Fourth, according to the existing situation, determine the boiler
room, according to the boiler room to choose the form of boiler,
such as horizontal or vertical and so on the production of heating
and production process with hot water boilers, sometimes can be
used as a peak heating boiler of thermal power station, in order to
adjust the heat network load.
The water temperature in the hot water boiler is lower than the
saturation temperature, compared with the steam boiler, the
temperature difference between the fume and water of the hot water
boiler is larger, the scale is less, the heat transfer condition is
better, and the hot water heating system is much smaller than the
heat loss of the steam heating system, so the hot water boiler has
a better energy saving effect for heating. China will have a
water-out temperature of more than 130 degrees C called a hot hot
water boiler, and a low-temperature hot water boiler with a
temperature temperature of less than 130 degrees C.
In the early days, most of the small-capacity low-temperature hot
water boilers were cast iron-to-chip combined boilers. This boiler
body is composed of a piece of cast iron pair, can be configured
according to the amount of heat produced to the number of pieces.
Cast iron has the characteristics of oxygen and acid corrosion
resistance to chip combined boilers, but it produces less heat and
is only used in applications with low heating.
Parameters
CWDR5.6-95/70
| NO; | Name | Unit | Number | Description |
| 1 | Rated efficiency | MW | 5.6 | |
| 2 | Water volume | M³ | 3.75 | |
| 3 | Rated outlet/inlet water temperature | ℃ | 95/70 | |
| 4 | Heating efficiency | % | 99 | |
| 5 | Output/inlet diameter | mm | DN125 | |
| 6 | Design fuels | / | Electric | |
| 7 | Blow down valve diameter | mm | DN125 | |
| 8 | Heating area(room) | ㎡ | 12500 | |
| 9 | Hot water output | M³/h | 36 | |
| 10 | Bulk size | mm | 8000×2800×2900 | |
Our services
Pre-sale service:
We help customer choose the best boiler model according to
different requirements of various industry. Before delivery we
will provide foundation drawing, layout drawing, boiler room
layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the
production process to ensure on time delivery with perfect
finished product.
After-sale service:
1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is
available.
3. Our engineers will held a training for boiler workers to
ensure the safe operation.
4. Free maintenance and repair for one year and lifelong
service.
Boiler application areas
