1t High efficiency environment protection automatic electric
heating thermal oil boiler
Electric heating heat transfer furnace system by explosion-proof
electric heater, organic heat carrier furnace, heat exchanger
(configurable), control cabinet, heat pump, expansion tank and
other combination into a pry block, the user only need to plug into
the power supply, media import and export pipe steam and some
electrical interface can be used. The thermal oil heater (also
known as the thermal oil heater) is to directly insert the electric
heater into the organic carrier (thermal oil) direct heating, using
the circulating pump, forcethe thermal oil to carry out liquid
phase circulation, transfer heat to one or more heat ingress, after
unloading with heat equipment, re-use the circulating pump, back to
the heater, and then absorb heat, pass to the heating equipment, so
that the continuous transfer of heat, so that heat is continuously
transferred, so that heat is heated. The thermal oil heater uses
several temperature control instrument control, with
super-temperature alarm, low oil level alarm, super-pressure alarm
function, it is chemical, petroleum, machinery, printing and
dyeing, food, ships, textiles, filmand and other industries in a
high-efficiency and energy-saving heating equipment.
parameters
DRYL-700
| NO; | Name | Unit | Number | Description |
| 1 | Rated thermal power | KW | 700 | |
| 2 | Rated working power | Mpa | 1.0 | |
| 3 | Rated inlet/outlet ℃ | ℃ | 310/290 | |
| 4 | Design efficiency | ％ | 92.45(Oil) 92.13(Gas) | |
| 5 | Boiler heat efficiency | ％ | More than 98% | Be added economizer |
| 6 | Design fuels | / | Light oil,Gas | |
| 7 | Fuels LHV | MJ/kg | 42.917(Oil) | |
| MJ/Nm3 | 35.438(Gas) | |
| 8 | Consumption of fuels | kg/h | 70.77(Oil) | |
| Nm³/h | 86.53(Gas) | Be added economizer |
| 9 | Radiation heating area | m² | 7.199 | |
| Convection heating area | m² | 28.71 | |
| GGH heating area | m² | 10.965 | |
| 10 | Fume temperature | ℃ | 136.68(Oil) | |
| ℃ | 137.02 (Gas) | |
| 11 | Fume temperature | ℃ | 60-80 | Be added economizer |
| 12 | Excess air coefficient | / | 1.15 | |
| 13 | Volume | m3 | 0.46 | |
| 14 | Bulk weight | kg | 4250 | |
| 15 | Bulk size | mm | 3256×1727×2181 | |
| 16 | Chimney | mm | Φ325×10000 | |
| 17 | Combustion model | / | Micro positive pressure | Chamber combustion |
| 18 | Boiler structure feature | Horizontal-type chamber combustion |
| 19 | Control way | Full automation/Manual |
| 20 | Ignition way | High-tension/Electrode |
Our services
Pre-sale service:
We help customer choose the best boiler model according to
different requirements of various industry. Before delivery we
will provide foundation drawing, layout drawing, boiler room
layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the
production process to ensure on time delivery with perfect
finished product.
After-sale service:
1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is
available.
3. Our engineers will held a training for boiler workers to
ensure the safe operation.
4. Free maintenance and repair for one year and lifelong
service.
Boiler application areas
