1,200,000 Kcal Fully Automatic Safety Low Pressure Oil Fired Gas
Fired Steam Boiler For Industries
Steam boilers play an important role in the production lines of the
chemical industry. Yixing City Must Clearwater Treatment Agent Co.,
Ltd. was founded in 2000, specializing in water treatment agent
polymer aluminum chloride research and production. In recent years,
the state pays more and more attention to environmental protection,
and the requirements are getting higher and higher. The use of
boilers has added many restrictions, "coal to gas", "coal to
electricity" and other policies are also continuing to advance.
Yixing City Must Clearwater Treatment Agent Co., Ltd. in order to
respond positively to environmental regulations, plans to use
natural gas as boiler fuel. Compared with coal-fired boilers, the
cost of natural gas is higher, in order to effectively control the
operating costs, the introduction of energy-saving and
environmentally friendly natural gas boilers is very important for
the enterprise. The gas boilers produced in China have excellent
advantages in terms of energy saving and environmental protection:
thermal efficiency can be as high as 98%, nitrogen oxide emissions
can be as low as 30 mg. After learning of the actual demand of Bing
Clearwater Treatment Agent Co., Ltd., the sales manager of
Zhongzheng Boiler recommended 2t/h WNS series gas steam boiler.
This WNS series gas boiler uses large diameter corrugated furnace
bile, with high-efficiency heat transfer element threaded pipe,
effectively improve thermal efficiency, and in the tail of the
boiler configuration condenser, energy saver and other related
equipment, the exhaust temperature can be reduced to 60 degrees,
can effectively save the enterprise a certain amount of fuel costs.
At the same time, this series of gas boilers with the
characteristics of fully automatic operation, not only improve the
reliability of operation, but also reduce the operation pressure of
the maintenance personnel.
Part of product parameters
WNS2-1.25-YQ
| NO; | Name | Unit | Number | Description |
| 1 | Rated evaporation | t/h | 2 | |
| 2 | Rated working power | Mpa | 1.25 | |
| 3 | Rated outlet ℃ | ℃ | 193 | |
| 4 | Design efficiency | ％ | 92.6(Oil) 92.46(Gas) | |
| 5 | Boiler heat efficiency | ％ | More than 98% | |
| 6 | Design fuels | / | Light oil,Gas | |
| 7 | Fuels LHV | MJ/kg | 42.917(Oil) | |
| MJ/Nm3 | 35.438(Gas) | |
| 8 | Consumption of fuels | kg/h | 137.9(Oil) | |
| Nm³/h | 167.325(Gas) | |
| 9 | Radiation heating area | m² | 8.527 | |
| Convection heating area | m² | 41.838 | |
| GGH heating area | m² | 23.195 | |
| 10 | Fume temperature | ℃ | 137.863(Oil) | |
| ℃ | 134.28 (Gas) | |
| 11 | Fume temperature | ℃ | 60-80 | |
| 12 | Excess air coefficient | / | 1.15 | |
| 13 | Volume | m3 | 5 | |
| 14 | Bulk weight | kg | 9700 | |
| 15 | Bulk size | mm | 4531×2150×2544 | |
| 16 | Chimney | mm | Φ500×10000 | |
| 17 | Total power consumption | KW | Oil:13,Gas:11 | |
| 18 | Combustion model | / | Micro positive pressure | Chamber combustion |
| 19 | Boiler structure feature(Three-pass structure) | Horizontal-type chamber combustion |
| 20 | Control way | Full automation/Manual |
| 21 | Ignition way | High-tension/Electrode |
Our services
Pre-sale service:
We help customer choose the best boiler model according to
different requirements of various industry. Before delivery we
will provide foundation drawing, layout drawing, boiler room
layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the
production process to ensure on time delivery with perfect
finished product.
After-sale service:
1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is
available.
3. Our engineers will held a training for boiler workers to
ensure the safe operation.
4 . Free maintenance and repair for one year and lifelong
service.
